Fairino Cobot FR3

Fairino Cobot FR3

The Fairino Cobot FR3 is the most agile member of the series, specifically engineered for intricate assembly and laboratory automation. With its lightweight 15kg body and a 3kg payload capacity, it delivers exceptional repeatability of ±0,02mm, making it the perfect solution for electronics testing and high-speed pick-and-place operations in confined workspaces.

Built with high-precision force sensors at every joint, the Fairino Cobot FR3 ensures maximum safety in shared workspaces. it features sensitive collision detection and a state-of-the-art safety management system, allowing it to work side-by-side with human operators without the need for bulky safety fences.

The Fairino Cobot FR3 series eliminates the complexity of robot programming. With its user-friendlu drag-and-teach interface and lightweight controller cabiner, the entire system can be deployed and operational within hours. it supports various industrial protocols and id compatible with a wide range of end-effectors, from vacuum grippers to precision cameras.

Technical data:

• Payload: 3kg
• Reach:622mm
• Repeatability: 0,02mm
• Weight: 15kg
• IP rating: IP54
• Footprint: 128mm
• Degrees of Freedom: 6 DOF
• Max TCP Speed: 1m/s
• Power Consumption: 150W
• Noise level: max 65dB
• Materials: aluminium alloy, industrial plastic
