Interface card Direct-Link PCUCANIO CANOPEN DRL-CNO-PCU

Molex DRL-CNO-PCU – Industrial Communication Card for PC/104 with CANopen Support (Code: 1120005035)

Product Description:
The Molex DRL-CNO-PCU is an industrial communication interface card designed for embedded systems using the PC/104 bus. It is ideal for applications in automation, distributed control, and mobile machinery. Featuring a built-in co-processor, the card offloads CANopen protocol management from the host CPU, ensuring deterministic response times and reliable performance for real-time distributed applications.

Key Features:

• Bus Interface: PC/104

• CAN Interface: 1 x CAN channel ISO 11898, DB9 connector, supports speeds up to 1 Mbps

• Protocol: CANopen Master/Slave (fully integrated protocol stack)

• Integrated Co-Processor: AMD SC520

• Memory: 16 MB SDRAM, 4 MB Flash

• Operating System Compatibility: Windows 8, 7, XP, Vista, Embedded Linux (on request)

• Included Tools: Configuration console, CANopen monitor, diagnostic tools, development libraries (C/C++, VB.Net, C#)

Benefits:

• High-performance CANopen communication on embedded platforms

• Supports both Master and Slave operating modes

• Compact solution for real-time distributed control systems

• Compliant with industrial standards: CE, RoHS, CANopen CiA

Typical Applications:

• Control of actuators and sensors in distributed networks

• Mobile machinery and industrial vehicles

• Embedded systems for decentralized automation

• Simulation and testing in CANopen environments
